Tractor · 1977Unverified
Steiger Panther III PT-350
Steiger Panther III PT-350 — III Series · 57 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
57 hp
Weight
13457 kg
Hover a source tag to verify
Overview
ManufacturerSteigerReference
Four-wheel Drive (4WD) tractorReference
Built in Fargo, North Dakota, USAReference
Original price was $95,000 in 1981Reference
Four-wheel driveReference
Final drivesoutboard planetaryReference
Articulated power steeringReference
Hydraulic disc brakesReference
Safari Cab standard with air-conditioning.Reference
Engine
Cummins 14.8L 8-cyl dieselReference
Engine261.0 kWReference
Cummins VT903Reference
turbocharged dieselReference
8-cylinderReference
liquid-cooled V-8Reference
Displacement14.8 LReference
Bore/Stroke140 x 121 mmReference
Power261.0 kWReference
Compression15.5:1Reference
Rated RPM2600Reference
Idle RPM830-2960Reference
Starter volts12Reference
Oil capacity36.0 LReference
Coolant capacity56.8 LReference
Transmission
20-speed constant meshReference
Typeconstant meshReference
Gears20 forward and 4 reverseReference
Clutchhydraulic cerametallic dry discReference
Oil capacity15.1 LReference
Oil capacity35.0 LReference
Five-speed transmission with two ranges and a two-speed transfer case. Tractor must be stopped to shift ranges on transmission or transfer case.Reference
PTO & Hydraulics
PTO (claimed)42.5 kWReference
PTO (claimed)78.3 kWReference
Hydraulic system83.3 LReference
Typeopen centerReference
Capacity83.3 LReference
Pressure155.1 barReference
Valves4 or 5Reference
Pump flow75.7 lpmReference
Rear TypeIIIReference
Rear PTOindependentReference
Clutchhydrostatic-driveReference
Rear PTO Type540/1000Reference
Capacities
Fuel851.6 LReference
Dimensions
Wheelbase336 cmReference
Weight13457 kgReference
Front tire20.8-34Reference
Rear tire20.8-34Reference
Ag front20.8-34Reference
Ag rear20.8-34Reference
Ag front23.1-30Reference
Ag front24.5-32Reference
Ag front30.5-32Reference
Ag front18.4-34Reference
Ag front23.1-34Reference
Ag front18.4-38Reference
Ag front20.8-38Reference
Ag rear23.1-30Reference
Ag rear24.5-32Reference
Ag rear30.5-32Reference
Ag rear18.4-34Reference
Ag rear23.1-34Reference
Ag rear18.4-38Reference
Ag rear20.8-38Reference
Length672 cmReference
Width305 cmReference
Height (exhaust)395 cmReference
Shipping weight13457 kgReference
Max weight15422 kgReference
Front axleSteiger S-34Reference
Steiger S-34 rear axleReference
Panther III PT-350 Serial Numbers
1977140-00001Reference
1978140-00023Reference
1979140-00059Reference
1980140-00062Reference
1981140-00075Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps90Reference
Charging volts12Reference
Batteries4Reference
Battery CCA475Reference
Battery volts12Reference
Speeds
With 20.8x34 tires and S-34 axles.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
