Tractor · 1978Unverified
Steiger Panther III PTA-297
Steiger Panther III PTA-297 — III Series · 105 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
105 hp
Weight
13143 kg
Hover a source tag to verify
Overview
ManufacturerSteigerReference
Four-wheel Drive (4WD) tractorReference
Built in Fargo, North Dakota, USAReference
Original price was $95,200 in 1982Reference
Four-wheel driveReference
Final drivesSteiger S-34 outboard planetaryReference
Articulated power steeringReference
Safari Cab standard with air-conditioning.Reference
Variants
PTA-296naturally aspiratedReference
PTA-297turbochargedReference
Engine
Cummins 14.8L 8-cyl dieselReference
Engine220.0 kWReference
Cummins VT-903Reference
turbocharged dieselReference
8-cylinderReference
liquid-cooled 90-degree V8Reference
Displacement14.8 LReference
Bore/Stroke140 x 121 mmReference
Power220.0 kWReference
Pre-heatingether injectionReference
Pre-heatingblock heaterReference
Rated RPM2600Reference
Idle RPM650-2860Reference
Torque949.2 NmReference
Torque RPM1800Reference
Starter volts12Reference
Oil capacity36.0 LReference
Coolant capacity64.4 LReference
Transmission
8-speed power shift with torque converterReference
TransmissionAllison HT-740Reference
Typepower shift with torque converterReference
Gears8 forward and 2 reverseReference
Four gears, plus reverse, with two-speed transfer case. Automatic torque converter lock-up.Reference
PTO & Hydraulics
PTO (claimed)78.3 kWReference
PTO (claimed)42.5 kWReference
Hydraulic system83.3 LReference
Typeopen center load sensingReference
Capacity83.3 LReference
Valves4Reference
Pump flow132.5 lpmReference
Total flow8516.2 lpmReference
Rear TypeIIIReference
Rear PTOindependentReference
ClutchElectrically-controlled hydraulic PTO drive.Reference
Rear PTO Type540 (1.375)Reference
Rear PTO Type1000 (1.75)Reference
Capacities
Fuel851.6 LReference
Dimensions
Wheelbase336 cmReference
Weight13143 kgReference
Front tire24.5-32Reference
Rear tire24.5-32Reference
Ag front24.5-32Reference
Ag rear24.5-32Reference
Ag front30.5-32Reference
Ag front20.8-38Reference
Ag rear30.5-32Reference
Ag rear20.8-38Reference
Length672 cmReference
Width99 cmReference
Width243 cmReference
Width356 cmReference
Shipping weight13143 kgReference
Max weight15422 kgReference
Electrical
Charging systemDelco-Remy alternatorReference
Charging amps90Reference
Batteries4Reference
Battery CCA475Reference
Battery volts12Reference
Steiger Panther III PTA-297 Height
Hood240 cmReference
Cab342 cmReference
Exhaust395 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
