Tractor · 1969Unverified
Steiger Tiger
Steiger Tiger — I Series · 205 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
205 hp
Weight
10886 kg
Hover a source tag to verify
Overview
ManufacturerSteigerReference
Four-wheel Drive (4WD) tractorReference
Built in Fargo, North Dakota, USAReference
Original price was $38,000 in 1972Reference
Four-wheel driveReference
Final drivesplanetaryReference
Articulated power steeringReference
Cab standard with available air-conditioning.Reference
Engine
Cummins 14.8L 8-cyl dieselReference
Fuel tank908.4 LReference
Engine238.6 kWReference
Cummins V903Reference
dieselReference
8-cylinderReference
liquid-cooledReference
Displacement14.8 LReference
Bore/Stroke140 x 121 mmReference
Power238.6 kWReference
Rated RPM2600Reference
Transmission
10-speedReference
TransmissionDana SST1010Reference
Gears10 forward and 2 reverseReference
PTO & Hydraulics
PTO (claimed)152.9 kWReference
Typeopen centerReference
Dimensions
Weight10886 kgReference
Front tire20.8-38Reference
Rear tire20.8-38Reference
Ag front20.8-38Reference
Ag rear20.8-38Reference
Ag front23.1-30Reference
Ag rear23.1-30Reference
Tiger Serial Numbers
1969850Reference
1970852Reference
1971859Reference
1972869Reference
FAQ: How to read a serial number table.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
