Tractor · 1973Unverified
Steiger Turbo Tiger
Steiger Turbo Tiger — I Series · 256 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
256 hp
Weight
21000 to 26000 pounds
Hover a source tag to verify
Overview
ManufacturerSteigerReference
Four-wheel Drive (4WD) tractorReference
Built in Fargo, North Dakota, USAReference
Original price was $39,000 in 1974Reference
Four-wheel driveReference
Final drivesoutboard planetaryReference
Steeringhydraulic articulated powerReference
Climatized Cab standard with available air-conditioning.Reference
Engine
Cummins 14.8L 8-cyl dieselReference
Engine238.6 kWReference
Drawbar (claimed)175.2 kWReference
Cummins VT-903Reference
turbocharged dieselReference
8-cylinderReference
liquid-cooled V-8Reference
Displacement14.8 LReference
Bore/Stroke140 x 121 mmReference
Power238.6 kWReference
Air cleanerdryReference
Rated RPM2600Reference
Torque1057.7 NmReference
Torque RPM1700Reference
StarterelectricReference
Starter volts12Reference
Oil capacity23.7 LReference
Coolant capacity56.8 LReference
Transmission
10-speed gearReference
TransmissionDana 1010Reference
TypegearReference
Gears10 forward and 2 reverseReference
Clutch355.6mm dry discReference
Oil capacity13.2 LReference
PTO & Hydraulics
PTO (claimed)190.9 kWReference
Hydraulic system143.8 LReference
Typeopen centerReference
Capacity143.8 LReference
Pressure137.9 barReference
Pump flow94.6 lpmReference
Capacities
Fuel783.5 LReference
Dimensions
Wheelbase308 cmReference
Weight21000 to 26000 poundsReference
Front tire30.5-32Reference
Rear tire30.5-32Reference
Ag front30.5-32Reference
Ag rear30.5-32Reference
Ag front23.1-30Reference
Ag front24.5-32Reference
Ag front20.8-38Reference
Ag rear23.1-30Reference
Ag rear24.5-32Reference
Ag rear20.8-38Reference
Length619 cmReference
Height (cab)339 cmReference
Shipping weight9525 kgReference
Operating weight11793 kgReference
Ground clearance42 cmReference
Turbo Tiger Serial Numbers
197330002Reference
197430063Reference
FAQ: How to read a serial number table.Reference
Electrical
Charging systemalternatorReference
Charging amps62Reference
Charging volts12Reference
Batteries2Reference
Battery volts12Reference
Speeds
With 30.5-32 tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
