Lawn Tractor · 2010Unverified
Steiner 235
Steiner 235 — Garden tractor · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
644 kg
Hover a source tag to verify
Overview
ManufacturerSteinerReference
Garden tractorReference
Two-wheel driveReference
Power steeringReference
Drum brakesReference
Open operator station. ROPS optional.Reference
Variants
75-7028225HP liquid-cooled diesel KubotaReference
75-7028335HP air-cooled gas VanguardReference
Engine
24.8HP Kubota 1122cc 3-cyl dieselReference
35HP Briggs & Stratton 991cc gasolineReference
Fuel tank22.7 LReference
Kubota D1105Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement68.5 ciReference
Power (gross)18.5 kWReference
Rated RPM3600Reference
StarterelectricReference
Starter volts12Reference
Briggs & Stratton VanguardReference
gasolineReference
air-cooledReference
The gas engine option was only available from 2011 to 2013.Reference
Displacement60.5 ciReference
Power (gross)26.1 kWReference
Transmission
hydrostaticReference
TransmissionSundstrand 15Reference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
Sundstrand Series 15 hydrostatic with Peerless 2600 two-speed transaxle.Reference
PTO & Hydraulics
Front PTOindependentReference
ClutchelectricReference
Dimensions
Wheelbase127 cmReference
Weight644 kgReference
Front tire24x11-2Reference
Rear tire18x8.50-8Reference
Lawn/turf front24x11-2Reference
Lawn/turf rear18x8.50-8Reference
Length208 cmReference
Width142 cmReference
Height114 cmReference
Steiner 235 attachments
60" front-mount mower deckReference
72" front-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
235D Charging amps40Reference
235G Charging amps20Reference
235D Battery CCA620Reference
235G Battery CCA525Reference
Battery volts12Reference
Attachment overview
60" front-mount mower deckReference
72" front-mount mower deckReference
SnowblowerReference
BladeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
