Tractor · 1974Unverified
Steyr 1400
Steyr 1400 · 140 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
140 hp
Weight
5660 kg
Hover a source tag to verify
Overview
ManufacturerSteyrReference
Built in Saint Valentin, AustriaReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Cab standard. Air-conditioning optional.Reference
Engine
Steyr 6.6L 6-cyl dieselReference
Fuel tank245.3 LReference
Engine104.4 kWReference
Steyr WD 612.85Reference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.6 LReference
Bore/Stroke108 x 120 mmReference
Power104.4 kWReference
Rated RPM2200Reference
Torque539.7 NmReference
Torque RPM1500Reference
Transmission
12-speedReference
TransmissionsynchroReference
Gears12 forward and 4 reverseReference
PTO & Hydraulics
Total flow40.9 lpmReference
Rear lift4520 kgReference
Rear PTO Type1000Reference
Dimensions
Wheelbase270 cmReference
Weight5660 kgReference
Front tire18.4-26Reference
Rear tire18.4-38Reference
Ag front18.4-26Reference
Ag rear18.4-38Reference
Length490 cmReference
Height275 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
