Tractor · 1947Unverified
Steyr 180
Steyr 180 — Model year 1947-19511951-1953 · 26 hp. Reference specifications; pending source verification.
The Steyr 180 is a compact tractor with a rated output of 26 hp, produced from 1947 to 1953. It features a 2-cylinder diesel liquid-cooled engine, coupled to a 5-speed gearbox, and is available with two-wheel drive. The listed weight of the Steyr 180 is 1799 kg, suitable for tasks covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
26 hp
Weight
1799 kg
Catalogue coverage
Variants represented
2
Richest spec table
44 rows
Recorded power
26 hp
Recorded weight
1799 kg
Transmissions
5-speed gear
Production years
1947-1953
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerSteyrReference
Standard-tread tractorReference
Two-wheel driveReference
Manual steeringReference
Mechanical drum brakesReference
Open operator station.Reference
Engine
Steyr 2.7L 2-cyl dieselReference
Fuel tank43.9 LReference
Engine (net)19.1 kWReference
Steyr WD 213Reference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement2.7 LReference
Bore/Stroke110 x 140 mmReference
Power (net)19.1 kWReference
Rated RPM1600Reference
StarterelectricReference
Starter volts12Reference
Oil capacity10.0 LReference
Coolant capacity13.0 LReference
Transmission
5-speed gearReference
TypegearReference
Gears5 forward and 1 reverseReference
PTO & Hydraulics
PTO (claimed)16.2 kWReference
Rear PTO Type540Reference
Engine RPM540@1420Reference
Dimensions
Wheelbase166 cmReference
Weight1799 kgReference
Front tire5.00-16Reference
Rear tire9.00-24Reference
Ag front5.00-16Reference
Ag rear9.00-24Reference
Ag front5.25-16Reference
Ag front5.50-16Reference
Ag rear10-24Reference
Ag rear11-24Reference
Length281 cmReference
Width151 cmReference
Height177 cmReference
Max weight2300 kgReference
Ground clearance26 cmReference
Front tread124 cmReference
Rear tread124 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
