The Steyr 185 is a tractor model with a rating of approximately 44 hp, positioning it at the lighter end of its class. Produced from 1955 to 1958, the 185 is equipped with a 3-cylinder diesel liquid-cooled engine and two-wheel drive, paired with a 6-speed gearbox. Its operating weight is listed as 2699 kg, suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
44 hp
Weight
2699 kg
Catalogue coverage
Variants represented
2
Richest spec table
33 rows
Recorded power
44 hp
Recorded weight
2699 kg
Transmissions
6-speed gear
Production years
1955-1958
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerSteyrReference
Standard-tread tractorReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
Steyr 4.0L 3-cyl dieselReference
Engine (net)33.1 kWReference
Steyr WD 313Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement4.0 LReference
Bore/Stroke110 x 140 mmReference
Power (net)33.1 kWReference
Rated RPM1600Reference
StarterelectricReference
Starter volts12Reference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 1 reverseReference
PTO & Hydraulics
PTO (claimed)31.6 kWReference
Rear PTO Type540Reference
Dimensions
Wheelbase205 cmReference
Weight2699 kgReference
Front tire6.50-20Reference
Rear tire13-30Reference
Ag front6.50-20Reference
Ag rear13-30Reference
Length333 cmReference
Width186 cmReference
Height217 cmReference
Front tread150 cmReference
Rear tread150 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
