The Steyr 185a is a compact tractor model with a rated output of 54 hp, making it a suitable option for smaller-scale agricultural tasks. It was manufactured from 1959 to 1968 and features a 3-cylinder diesel liquid-cooled engine. The tractor is equipped with two-wheel drive and a 6-speed gearbox, with a listed weight of 2699 kg. It is designed for use on plots of land up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
54 hp
Weight
2699 kg
Catalogue coverage
Variants represented
2
Richest spec table
33 rows
Recorded power
54 hp
Recorded weight
2699 kg
Transmissions
6-speed gear
Production years
1959-1968
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerSteyrReference
Standard-tread tractorReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
Steyr 4.0L 3-cyl dieselReference
Engine (net)40.5 kWReference
Steyr WD 313aReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement4.0 LReference
Bore/Stroke110 x 140 mmReference
Power (net)40.5 kWReference
Rated RPM1750Reference
StarterelectricReference
Starter volts12Reference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 1 reverseReference
PTO & Hydraulics
PTO (claimed)39.0 kWReference
Rear PTO Type540Reference
Dimensions
Wheelbase205 cmReference
Weight2699 kgReference
Front tire6.50-20Reference
Rear tire13-30Reference
Ag front6.50-20Reference
Ag rear13-30Reference
Length333 cmReference
Width186 cmReference
Height217 cmReference
Front tread150 cmReference
Rear tread150 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
