Tractor · 1967Unverified
Steyr 40
Steyr 40 — Plus Series · 38 hp. Reference specifications; pending source verification.
The Steyr 40 is a compact tractor model, boasting a rated output of 38 hp. It was manufactured from 1967 to 1970 and features a 3-cylinder diesel liquid-cooled engine, which powers the four-wheel drive system via an 8-speed gearbox. The listed weight of the Steyr 40 ranges from 4123 to 4674 pounds. It is suited for tasks covering approximately 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
38 hp
Weight
4123 to 4674 pounds
Catalogue coverage
Variants represented
2
Richest spec table
43 rows
Recorded power
38 hp
Transmissions
8-speed
Production years
1967-1970
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerSteyrReference
Utility tractorReference
Two- or four-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
40Afour-wheel driveReference
Engine
Steyr 2.3L 3-cyl dieselReference
Fuel tank62.1 LReference
Engine28.3 kWReference
Steyr WD 307.40Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.3 LReference
Bore/Stroke98 x 100 mmReference
Power28.3 kWReference
Rated RPM2400Reference
Torque147.8 NmReference
Torque RPM1400Reference
Transmission
8-speedReference
TransmissiongearReference
Gears8 forward and 6 reverseReference
PTO & Hydraulics
Total flow22.0 lpmReference
Rear TypeII/IReference
Rear lift1350 kgReference
Rear PTO Type540Reference
Dimensions
Wheelbase195 cmReference
Weight4123 to 4674 poundsReference
Front tire6.00-16Reference
Rear tire12.4-28Reference
Ag front6.00-16Reference
Ag rear12.4-28Reference
Ag front6.50-20Reference
Length332 cmReference
Width161 cmReference
Height153 cmReference
2WD Front tread127 cmReference
4WD Front tread137 cmReference
Rear tread135 cmReference
2WD1870 kgReference
4WD2120 kgReference
Capacities
2WD Max capacity2849 kgReference
4WD Max capacity3099 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
