Tractor · 2013Unverified

Steyr 4115 Multi

Name: Steyr 4115 Multi
Brand: Steyr

Steyr 4115 Multi — Multi Series · 114 hp. Reference specifications; pending source verification.

The Steyr 4115 Multi is a tractor with a rated output of 114 hp, positioning it within its class for power. It was manufactured between 2013 and 2015. The tractor features a 4-cylinder turbocharged intercooled diesel liquid-cooled engine, coupled with a powershift transmission and four-wheel drive. Its listed weight is 4500 kg, making it suitable for tasks ranging from 200 to 800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

114 hp

Weight

4500 kg

Catalogue coverage

Variants represented

Richest spec table

60 rows

Recorded power

114 hp

Recorded weight

4500 kg

Transmissions

32-speed four-speed power shift

Production years

2013-2015

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerSteyrReference

Utility tractorReference

Built in Saint Valentin, AustriaReference

Four-wheel driveReference

Differential lockelectro-hydraulicReference

Power steeringReference

Wet disc brakesReference

Cab standard with air-conditioning.Reference

Engine

Iveco 3.4L 4-cyl dieselReference

Fuel tank149.9 LReference

Engine (gross)85.0 kWReference

IvecoReference

turbocharged intercooled dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.4 LReference

Bore/Stroke99 x 110 mmReference

Rated Power (gross)85.0 kWReference

Rated RPM2200Reference

Torque457.1 NmReference

Torque RPM1500Reference

StarterelectricReference

Starter volts12Reference

Transmission

32-speed four-speed power shiftReference

Typefour-speed power shiftReference

Gears32 forward and reverseReference

four gears in four ranges, with an additional two-range shift.Reference

PTO & Hydraulics

Typeopen centerReference

Typeclosed center load-sensingReference

Rear valves4 (max)Reference

Mid valves2 (max)Reference

Pump flow60.0 lpmReference

Pump flow99.9 lpmReference

Rear PTOindependentReference

Rear PTO Type540/540E/1000/1000EReference

Engine RPM540@1805Reference

Engine RPM540E@1542Reference

Engine RPM1000@1880Reference

Engine RPM1000E@1606Reference

Front PTOindependentReference

Front PTO Type1000Reference

Engine RPM1000@1920Reference

Dimensions

Wheelbase242 cmReference

Weight4500 kgReference

Front tire480/65R24Reference

Rear tire540/65R38Reference

Standard tires (ag)Front: 480/65R24. Rear: 540/65R38Reference

Length440 cmReference

Width210 cmReference

Height (cab)272 cmReference

Height (cab)274 cmReference

Ground clearance45 cmReference

Front tread175 cmReference

Rear tread163 cmReference

Shipping4500 kgReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Capacities

Max capacity7500 kgReference

Max capacity7800 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
