Tractor · 2016Unverified
Steyr 4120 Multi
Steyr 4120 Multi — Multi Series · 117 hp. Reference specifications; pending source verification.
The Steyr 4120 Multi is a tractor with a rated output of 117 hp, placing it within the middle of its class in terms of power. The 4120 Multi model was first produced in 2016. It features a 4-cylinder turbocharged intercooled diesel liquid-cooled engine, paired with a powershift transmission and four-wheel drive. The tractor is designed for use on areas of around 200-800 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
117 hp
Catalogue coverage
Variants represented
2
Richest spec table
25 rows
Recorded power
117 hp
Transmissions
32-speed four-speed power shift
Production years
2016-2016
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerSteyrReference
Utility tractorReference
Built in Saint Valentin, AustriaReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Iveco 3.4L 4-cyl dieselReference
Engine (gross)87.2 kWReference
IvecoReference
turbocharged intercooled dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.4 LReference
Bore/Stroke99 x 110 mmReference
Rated Power (gross)87.2 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
32-speed four-speed power shiftReference
Typefour-speed power shiftReference
Gears32 forward and reverseReference
four gears in four ranges, with an additional two-range shift.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
