The Steyr 540 is a compact tractor model rated at 40 hp. It was manufactured between 1974 and 1977. The 540 features a 3-cylinder diesel liquid-cooled engine, driving through four-wheel drive with an 8-speed gearbox. The listed weight for this tractor is 2120 kg, suitable for tasks covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
40 hp
Weight
2120 kg
Catalogue coverage
Variants represented
2
Richest spec table
34 rows
Recorded power
40 hp
Recorded weight
2120 kg
Transmissions
8-speed
Production years
1974-1977
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerSteyrReference
Utility tractorReference
Built in Saint Valentin, AustriaReference
Two- or four-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
Steyr 2.4L 3-cyl dieselReference
Fuel tank62.1 LReference
Engine29.8 kWReference
Steyr WD 308.40Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.4 LReference
Bore/Stroke100 x 100 mmReference
Power29.8 kWReference
Rated RPM2400Reference
Torque153.2 NmReference
Torque RPM1400Reference
Transmission
8-speedReference
TransmissiongearReference
Gears8 forward and 6 reverseReference
PTO & Hydraulics
Total flow22.0 lpmReference
Rear lift1349 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase195 cmReference
Weight2120 kgReference
Front tire6.00-16Reference
Rear tire12.4-28Reference
Ag front6.00-16Reference
Ag rear12.4-28Reference
Ag front6.50-20Reference
Length332 cmReference
Height152 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
