Tractor · 2003Unverified
Steyr 6155 CVT
Steyr 6155 CVT — Utility tractor · 156 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
156 hp
Weight
6491 kg
Hover a source tag to verify
Overview
ManufacturerSteyrReference
Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
STEYR luxury cabReference
Engine
Sisu 6.6L 6-cyl dieselReference
Fuel tank310.0 LReference
Engine116.3 kWReference
SisuReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.6 LReference
Bore/Stroke108 x 120 mmReference
Power116.3 kWReference
Rated RPM2100Reference
Torque660.4 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Transmission
continuously variable transmission (CVT)Reference
Typecontinuously variable transmission (CVT)Reference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Pressure205.0 barReference
Valves5Reference
Total flow104.8 lpmReference
Rear TypeIII/IIReference
Rear lift9902 kgReference
Front lift4001 kgReference
Rear PTO Type540/540E/1000/1000EReference
Front PTO Type1000Reference
Dimensions
Wheelbase280 cmReference
Weight6491 kgReference
Front tire540/65R28Reference
Rear tire650/65R38Reference
Ag front540/65R28Reference
Ag rear650/65R38Reference
Length474 cmReference
Width248 cmReference
Height299 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
