Tractor · 2007Unverified

Steyr 6160 CVT

Name: Steyr 6160 CVT
Brand: Steyr

Steyr 6160 CVT — Utility tractor · 160 hp. Reference specifications; pending source verification.

The Steyr 6160 CVT is a tractor with a rated power of 160 hp, placing it at the more powerful end of its class. It was manufactured from 2007 to 2012. The tractor is equipped with a 6-cylinder turbocharged intercooled diesel liquid-cooled engine, paired with four-wheel drive and a continuously variable transmission. Its listed operating weight is 6490 kg, making it suitable for operations of 600–1,500 ac.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

160 hp

Weight

6490 kg

Catalogue coverage

Variants represented

Richest spec table

56 rows

Recorded power

160 hp

Recorded weight

6490 kg

Transmissions

continuously variable transmission (CVT)

Production years

2007-2012

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerSteyrReference

Utility tractorReference

Four-wheel driveReference

Power steeringReference

Hydraulic wet disc brakesReference

Trailer brakespneumaticReference

Trailer brakeshydraulicReference

Steyr luxury cab standard with air-conditioning.Reference

Engine

Sisu 6.6L 6-cyl dieselReference

Fuel tank310.0 LReference

Engine (gross)119.3 kWReference

Engine (max)136.5 kWReference

SisuReference

turbocharged intercooled dieselReference

6-cylinderReference

liquid-cooledReference

Displacement6.6 LReference

Bore/Stroke108 x 120 mmReference

Rated Power (gross)119.3 kWReference

Maximum Power (gross)136.5 kWReference

Rated RPM2100Reference

Operating RPM1800-2100Reference

Torque675.2 NmReference

Torque RPM1400Reference

Starter typenegativeReference

Transmission

continuously variable transmission (CVT)Reference

Typecontinuously variable transmission (CVT)Reference

Gearsinfinite forward and reverseReference

PTO & Hydraulics

Valves8 (max)Reference

Pump flow104.8 lpmReference

Rear TypeIII/IIReference

Rear lift9902 kgReference

Front lift4001 kgReference

Rear PTOindependentReference

Rear PTO Type540/540E/1000/1000E (1.375)Reference

Engine RPM540@1878Reference

Engine RPM540E@1608Reference

Engine RPM1000@1869Reference

Engine RPM1000E@1600Reference

Front PTOindependentReference

Front PTO Type1000Reference

Dimensions

Wheelbase280 cmReference

Weight6490 kgReference

Front tire540/65Reference

Rear tire650/65Reference

Ag front540/65 R28Reference

Ag rear650/65 R38Reference

Length477 cmReference

Width255 cmReference

Height304 cmReference

Shipping weight6490 kgReference

Max weight11500 kgReference

Front tread189 cmReference

Rear tread186 cmReference

Electrical

GroundelectricReference

Charging systemalternatorReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
