Tractor · 2007Unverified
Steyr 6175 CVT
Steyr 6175 CVT — Utility tractor · 175 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
175 hp
Weight
6769 kg
Hover a source tag to verify
Overview
ManufacturerSteyrReference
Utility tractorReference
Four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Trailer brakespneumaticReference
Trailer brakeshydraulicReference
Steyr luxury cab standard with air-conditioning.Reference
Engine
Sisu 6.6L 6-cyl dieselReference
Fuel tank310.0 LReference
Engine (gross)130.5 kWReference
Engine (max)149.1 kWReference
SisuReference
turbocharged intercooled dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.6 LReference
Bore/Stroke108 x 120 mmReference
Rated Power (gross)130.5 kWReference
Maximum Power (gross)149.1 kWReference
Rated RPM2100Reference
Operating RPM1800-2100Reference
Torque745.1 NmReference
Torque RPM1400Reference
Starter typenegativeReference
Transmission
continuously variable transmission (CVT)Reference
Typecontinuously variable transmission (CVT)Reference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Valves8 (max)Reference
Pump flow129.8 lpmReference
Rear TypeIII/IIReference
Rear lift9902 kgReference
Front lift4001 kgReference
Rear PTOindependentReference
Rear PTO Type540/540E/1000/1000E (1.375)Reference
Engine RPM540@1878Reference
Engine RPM540E@1608Reference
Engine RPM1000@1869Reference
Engine RPM1000E@1600Reference
Front PTOindependentReference
Front PTO Type1000Reference
Dimensions
Wheelbase283 cmReference
Weight6769 kgReference
Front tire540/65Reference
Rear tire650/65Reference
Ag front540/65 R30Reference
Ag rear650/65 R42Reference
Length477 cmReference
Width255 cmReference
Height304 cmReference
Shipping weight6769 kgReference
Max weight11500 kgReference
Front tread190 cmReference
Rear tread186 cmReference
Electrical
GroundelectricReference
Charging systemalternatorReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
