Tractor · 2003Unverified

Steyr 6190 CVT

Steyr 6190 CVT — Utility tractor · 193 hp. Reference specifications; pending source verification.

The Steyr 6190 CVT is a tractor with a rated power output of 193 hp, placing it at the more powerful end of its class. It was manufactured between 2003 and 2005. The tractor features a 6-cylinder turbocharged diesel liquid-cooled engine, coupled with four-wheel drive and a continuously variable transmission. Its listed operating weight is 6772 kg, making it suitable for operations spanning approximately 600–1,500 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
193 hp
Weight
6772 kg

Catalogue coverage

Variants represented
2
Richest spec table
43 rows
Recorded power
193 hp
Recorded weight
6772 kg
Transmissions
continuously variable transmission (CVT)
Production years
2003-2005
Verified variants
0

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerSteyrReference
Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
STEYR luxury cabReference

Engine

Sisu 6.6L 6-cyl dieselReference
Fuel tank310.0 LReference
Engine143.9 kWReference
SisuReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.6 LReference
Bore/Stroke108 x 120 mmReference
Power143.9 kWReference
Rated RPM2100Reference
Torque790.5 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference

Transmission

continuously variable transmission (CVT)Reference
Typecontinuously variable transmission (CVT)Reference
Gearsinfinite forward and reverseReference

PTO & Hydraulics

Pressure205.0 barReference
Valves5Reference
Total flow129.8 lpmReference
Rear TypeIII/IIReference
Rear lift9902 kgReference
Front lift4001 kgReference
Rear PTO Type540/540E/1000/1000EReference
Front PTO Type1000Reference

Dimensions

Wheelbase283 cmReference
Weight6772 kgReference
Front tire540/65R28Reference
Rear tire650/65R38Reference
Ag front540/65R28Reference
Ag rear650/65R38Reference
Length476 cmReference
Width248 cmReference
Height299 cmReference

Electrical

GroundnegativeReference
Charging systemalternatorReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
