The Steyr 70 is a tractor with a rated power of 70 hp, falling within the mid-range for its class. Produced between 1968 and 1975, the model features a 4-cylinder diesel engine and mechanical front-wheel drive with a hydrostatic transmission. The listed operating weight is 3570 kg, and it is suited to operations of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
70 hp
Weight
3570 kg
Catalogue coverage
Variants represented
2
Richest spec table
31 rows
Recorded power
70 hp
Recorded weight
3570 kg
Transmissions
12-speed
Production years
1968-1975
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerSteyrReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD optionalReference
Steeringhydrostatic powerReference
Engine
4.0L 4-cyl dieselReference
Fuel tank107.9 LReference
Engine52.2 kWReference
WD 410tReference
dieselReference
4-cylinderReference
Displacement4.0 LReference
Bore/Stroke105 x 115 mmReference
Power52.2 kWReference
Rated RPM2400Reference
Torque250.0 NmReference
Torque RPM1400Reference
Transmission
12-speedReference
TransmissionsynchroReference
Gears12 forward and 6 reverseReference
PTO & Hydraulics
Total flow32.2 lpmReference
Rear lift2900 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase233 cmReference
Weight3570 kgReference
Front tire7.50-20Reference
Rear tire16.9-34Reference
Ag front7.50-20Reference
Ag rear16.9-34Reference
Ag front10.5-20Reference
Length387 cmReference
Height236 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
