The Steyr 80 is a compact tractor, rated at 15 hp, which places it among the smaller models in its class. Manufactured from 1949 to 1964, the Steyr 80 features a 1-cylinder diesel liquid-cooled engine and a 4-speed gearbox operating in two-wheel drive. Its listed weight is 1200 kg, and it is suitable for tasks on plots of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
15 hp
Weight
1200 kg
Catalogue coverage
Variants represented
2
Richest spec table
39 rows
Recorded power
15 hp
Recorded weight
1200 kg
Transmissions
4-speed gear
Production years
1949-1964
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerSteyrReference
Standard-tread tractorReference
Two-wheel driveReference
Differential lockmechanical rearReference
Manual steeringReference
Mechanical drum brakesReference
Open operator station.Reference
Variants
80standard chassisReference
80arow-crop chassisReference
80snarrow chassisReference
Engine
Steyr 1.3L 1-cyl dieselReference
Engine (net)11.0 kWReference
Steyr WD 113Reference
dieselReference
1-cylinderReference
liquid-cooledReference
Displacement1.3 LReference
Bore/Stroke110 x 140 mmReference
Power (net)11.0 kWReference
Rated RPM1500Reference
StarterelectricReference
Starter volts12Reference
Transmission
4-speed gearReference
TypegearReference
Gears4 forward and 1 reverseReference
PTO & Hydraulics
Rear PTOtransmissionReference
Rear PTO Type540Reference
Dimensions
Wheelbase165 cmReference
Weight1200 kgReference
Front tire4.00-15Reference
Rear tire8-24Reference
Ag front4.00-15Reference
Ag rear8-24Reference
Ag rear9-24Reference
Length288 cmReference
Width147 cmReference
Height167 cmReference
Front tread124 cmReference
Rear tread104 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
