Tractor · 1979Unverified
Steyr 8070
Steyr 8070 — Model year 1979-19841984-1992 · 59 hp. Reference specifications; pending source verification.
The Steyr 8070 is a tractor rated at 59 hp, positioned at the lighter end of its class. It was manufactured from 1979 to 1992 and features a 4-cylinder diesel liquid-cooled engine, paired with four-wheel drive and an 8-speed gearbox. The tractor's operating weight ranges from 5930 to 6613 pounds. It is suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
59 hp
Weight
5930 to 6613 pounds
Catalogue coverage
Variants represented
2
Richest spec table
39 rows
Recorded power
59 hp
Transmissions
8-speed synchronized
Production years
1979-1992
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerSteyrReference
Two- or four-wheel driveReference
Power steeringReference
Variants
80702WDReference
8070A4WDReference
Engine
Steyr 3.5L 4-cyl dieselReference
Fuel tank60.2 LReference
Engine43.6 kWReference
Steyr WD 411.42Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.5 LReference
Bore/Stroke100 x 110 mmReference
Power43.6 kWReference
Rated RPM2400Reference
Torque214.2 NmReference
Torque RPM1600Reference
Transmission
8-speed synchronizedReference
16-speed synchronizedReference
TypesynchronizedReference
Gears8 forward and reverseReference
Gears16 forward and 8 reverseReference
PTO & Hydraulics
Total flow37.1 lpmReference
Rear lift2600 kgReference
Rear PTO Type540/1000Reference
Dimensions
2WD Wheelbase215 cmReference
4WD Wheelbase217 cmReference
Weight5930 to 6613 poundsReference
Front tire7.50-16Reference
2WD Rear tire12.4-36Reference
2WD Standard tires (ag)Front: 7.50-16 . Rear: 12.4-36Reference
4WD Standard tires (ag)Front: 10.5-20. Rear: 12.4-36Reference
Length372 cmReference
Height246 cmReference
2WD2689 kgReference
4WD2999 kgReference
Capacities
2WD Max capacity4300 kgReference
4WD Max capacity4399 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
