Tractor · 1978Unverified
Steyr 8120
Steyr 8120 · 100 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
100 hp
Weight
4400 kg
Hover a source tag to verify
Overview
ManufacturerSteyrReference
Two- or four-wheel driveReference
Steeringhydrostatic powerReference
Disc brakesReference
Engine
Steyr 5.2L 6-cyl dieselReference
Fuel tank121.9 LReference
Engine74.6 kWReference
Steyr WD 611.86Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.2 LReference
Bore/Stroke100 x 110 mmReference
Power74.6 kWReference
Rated RPM2300Reference
Torque370.2 NmReference
Torque RPM1400Reference
Transmission
12-speedReference
15-speedReference
TransmissionsynchroReference
Gears12 forward and 4 reverseReference
Gears15 forward and 5 reverseReference
PTO & Hydraulics
Total flow34.8 lpmReference
Rear lift4300 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase254 cmReference
Weight4400 kgReference
Front tire9.00-16Reference
Rear tire18.4R34Reference
Ag front9.00-16Reference
Ag rear18.4R34Reference
Ag front13.6R24Reference
Length427 cmReference
Height262 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
