The Steyr 8160 is a tractor rated at 140 hp, placing it at the powerful end of its class. It was produced between 1976 and 1981. It features a 6-cylinder diesel liquid-cooled engine, paired with four-wheel drive and a hydrostatic transmission. The tractor has an operating weight of 5660 kg and is suited to operations of 200–800 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
140 hp
Weight
5660 kg
Catalogue coverage
Variants represented
2
Richest spec table
31 rows
Recorded power
140 hp
Recorded weight
5660 kg
Transmissions
12-speed
Production years
1976-1981
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerSteyrReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Disc brakesReference
Engine
Steyr 6.6L 6-cyl dieselReference
Fuel tank245.3 LReference
Engine104.4 kWReference
Steyr WD 612.85Reference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.6 LReference
Bore/Stroke108 x 120 mmReference
Power104.4 kWReference
Rated RPM2200Reference
Torque539.7 NmReference
Torque RPM1500Reference
Transmission
12-speedReference
TransmissionsynchroReference
Gears12 forward and 4 reverseReference
PTO & Hydraulics
Total flow40.9 lpmReference
Rear lift4520 kgReference
Rear PTO Type1000Reference
Dimensions
Wheelbase270 cmReference
Weight5660 kgReference
Front tire18.4-26Reference
Rear tire18.4-38Reference
Ag front18.4-26Reference
Ag rear18.4-38Reference
Length490 cmReference
Height275 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
