Tractor · 1987Unverified
Steyr 8320
Steyr 8320 · 280 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
280 hp
Weight
5151 kg
Hover a source tag to verify
Overview
ManufacturerSteyrReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Engine
9.7L 6-cyl dieselReference
Fuel tank380.0 LReference
Engine208.8 kWReference
WD 615.85Reference
turbo dieselReference
6-cylinderReference
Displacement9.7 LReference
Bore/Stroke126 x 130 mmReference
Power208.8 kWReference
Rated RPM2400Reference
Torque1110.6 NmReference
Torque RPM1500Reference
PTO & Hydraulics
Total flow26.9 lpmReference
Rear lift6001 kgReference
Rear PTO Type1000Reference
Dimensions
Wheelbase236 cmReference
Weight5151 kgReference
Front tire14.5-20Reference
Rear tire18.4-30Reference
Ag front14.5-20Reference
Ag rear18.4-30Reference
Length456 cmReference
Height325 cmReference
Transmission
Transmissionhydrostatic (3-range)Reference
Gearsinfinite forward and reverseReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
