Tractor · 1987Unverified

Steyr 8320

Name: Steyr 8320
Brand: Steyr

Steyr 8320 · 280 hp. Reference specifications; pending source verification.

The Steyr 8320 is a tractor model with a rated output of 280 hp, categorising it as a high-powered machine in its class. It was manufactured from 1987 to 1993. The tractor features a 6-cylinder turbocharged diesel engine, which drives through four-wheel drive via a hydrostatic transmission. It has a listed weight of 5151 kg and is designed for use on large areas of land, typically exceeding 1,500 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

280 hp

Weight

5151 kg

Catalogue coverage

Variants represented

Richest spec table

28 rows

Recorded power

280 hp

Recorded weight

5151 kg

Transmissions

hydrostatic (3-range)

Production years

1987-1993

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerSteyrReference

Four-wheel driveReference

Steeringhydrostatic powerReference

Engine

9.7L 6-cyl dieselReference

Fuel tank380.0 LReference

Engine208.8 kWReference

WD 615.85Reference

turbo dieselReference

6-cylinderReference

Displacement9.7 LReference

Bore/Stroke126 x 130 mmReference

Power208.8 kWReference

Rated RPM2400Reference

Torque1110.6 NmReference

Torque RPM1500Reference

PTO & Hydraulics

Total flow26.9 lpmReference

Rear lift6001 kgReference

Rear PTO Type1000Reference

Dimensions

Wheelbase236 cmReference

Weight5151 kgReference

Front tire14.5-20Reference

Rear tire18.4-30Reference

Ag front14.5-20Reference

Ag rear18.4-30Reference

Length456 cmReference

Height325 cmReference

Transmission

Transmissionhydrostatic (3-range)Reference

Gearsinfinite forward and reverseReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
