Tractor · 2008Unverified
Steyr 9085MT
Steyr 9085MT — Utility tractor · 86 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
86 hp
Weight
4179 kg
Hover a source tag to verify
Overview
ManufacturerSteyrReference
Utility tractorReference
Four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Trailer brakespneumaticReference
Trailer brakeshydraulicReference
Cab standard with heater. Available air-conditioning.Reference
Engine
Sisu 4.4L 4-cyl dieselReference
Fuel tank99.9 LReference
Engine (gross)63.8 kWReference
Engine (max)64.1 kWReference
SisuReference
turbocharged intercooled dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke108 x 120 mmReference
EmissionsTier IIIReference
Rated Power (gross)63.8 kWReference
Maximum Power (gross)64.1 kWReference
Rated RPM2300Reference
Torque330.1 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speedReference
TransmissionPower-2Reference
Gears16 forward and 8 reverseReference
PTO & Hydraulics
Pressure175.0 barReference
Valves2 or 3Reference
Pump flow50.0 lpmReference
Pump flow85.9 lpmReference
Steering flow34.1 lpmReference
Rear lift4900 kgReference
Front lift2499 kgReference
Rear PTOindependentReference
Rear PTO Type430/540/540E/1000Reference
Engine RPM430@2130Reference
Engine RPM540@2045Reference
Engine RPM540E@1506Reference
Engine RPM1000@2130Reference
Front PTOindependentReference
Front PTO Type1000Reference
Dimensions
Wheelbase248 cmReference
Weight4179 kgReference
Front tire14.9R24Reference
Rear tire18.4R34Reference
Standard tires (ag)Front: 14.9R24. Rear: 18.4R34Reference
Length421 cmReference
Width216 cmReference
Height (cab)273 cmReference
Shipping weight4179 kgReference
Max weight7199 kgReference
Front tread169 cmReference
Rear tread169 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
