Tractor · 1995Unverified

Steyr 9160

Name: Steyr 9160
Brand: Steyr

Steyr 9160 · 160 hp. Reference specifications; pending source verification.

The Steyr 9160 is a tractor rated at approximately 160 hp, placing it at the more powerful end of its class. It was produced between 1995 and 1997. The model is equipped with a 6-cylinder turbocharged diesel engine and four-wheel drive, paired with a hydrostatic transmission. Its listed operating weight is 6051 kg, making it suitable for operations on areas of 600–1,500 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

160 hp

Weight

6051 kg

Catalogue coverage

Variants represented

Richest spec table

30 rows

Recorded power

160 hp

Recorded weight

6051 kg

Transmissions

32-speed

Production years

1995-1997

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerSteyrReference

Four-wheel driveReference

Steeringhydrostatic powerReference

Disc brakesReference

Engine

6.6L 6-cyl dieselReference

Fuel tank269.9 LReference

Engine119.3 kWReference

620DSReference

turbo dieselReference

6-cylinderReference

Displacement6.6 LReference

Bore/Stroke108 x 120 mmReference

Power119.3 kWReference

Rated RPM2200Reference

Torque665.8 NmReference

Torque RPM1500Reference

Transmission

32-speedReference

TransmissionsynchroReference

Gears32 forward and reverseReference

PTO & Hydraulics

Total flow110.1 lpmReference

Rear lift8581 kgReference

Rear PTO Type540/1000Reference

Dimensions

Wheelbase293 cmReference

Weight6051 kgReference

Front tire18.4R26Reference

Rear tire20.8R38Reference

Ag front18.4R26Reference

Ag rear20.8R38Reference

Length516 cmReference

Height303 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
