The Steyr 9180 is a tractor with a rated power of 180 hp, placing it at the powerful end of its class. Built from 1995 to 1997, this model is powered by a 6-cylinder turbocharged diesel engine and features four-wheel drive with a hydrostatic transmission. The tractor has an operating weight of 6101 kg and is suited to operations of 600–1,500 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
180 hp
Weight
6101 kg
Catalogue coverage
Variants represented
2
Richest spec table
30 rows
Recorded power
180 hp
Recorded weight
6101 kg
Transmissions
32-speed
Production years
1995-1997
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerSteyrReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Disc brakesReference
Engine
6.6L 6-cyl dieselReference
Fuel tank330.1 LReference
Engine134.2 kWReference
620DSReference
turbo dieselReference
6-cylinderReference
Displacement6.6 LReference
Bore/Stroke108 x 120 mmReference
Power134.2 kWReference
Rated RPM2200Reference
Torque739.0 NmReference
Torque RPM1500Reference
Transmission
32-speedReference
TransmissionsynchroReference
Gears32 forward and reverseReference
PTO & Hydraulics
Total flow110.1 lpmReference
Rear lift8581 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase293 cmReference
Weight6101 kgReference
Front tire480/70R30Reference
Rear tire20.8R32Reference
Ag front480/70R30Reference
Ag rear20.8R32Reference
Length516 cmReference
Height308 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
