The Steyr 9200 is a tractor model with a rated output of 200 hp, positioning it within the higher-powered machines in its class. Production of this model spanned the years 1995 to 1997. The 9200 is equipped with a 6-cylinder turbocharged diesel engine, coupled with a hydrostatic transmission and four-wheel drive. Its listed weight is 6301 kg, suitable for handling tasks of approximately 600–1,500 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
200 hp
Weight
6301 kg
Catalogue coverage
Variants represented
2
Richest spec table
30 rows
Recorded power
200 hp
Recorded weight
6301 kg
Transmissions
32-speed
Production years
1995-1997
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerSteyrReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Disc brakesReference
Engine
7.4L 6-cyl dieselReference
Fuel tank330.1 LReference
Engine149.1 kWReference
634DSReference
turbo dieselReference
6-cylinderReference
Displacement7.4 LReference
Bore/Stroke108 x 134 mmReference
Power149.1 kWReference
Rated RPM2200Reference
Torque829.9 NmReference
Torque RPM1500Reference
Transmission
32-speedReference
TransmissionsynchroReference
Gears32 forward and reverseReference
PTO & Hydraulics
Total flow110.1 lpmReference
Rear lift8581 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase293 cmReference
Weight6301 kgReference
Front tire480/70R30Reference
Rear tire20.8R42Reference
Ag front480/70R30Reference
Ag rear20.8R42Reference
Length516 cmReference
Height308 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
