Tractor · 2000Unverified

Steyr CVT 120

Name: Steyr CVT 120
Brand: Steyr

Steyr CVT 120 · 120 hp. Reference specifications; pending source verification.

The Steyr CVT 120 is a high-powered tractor, rated at 120 hp, and was produced between 2000 and 2003. It features a 6-cylinder turbocharged diesel engine, coupled with a continuously variable transmission and four-wheel drive. The tractor's listed weight is 6271 kg, making it suitable for tasks covering approximately 200-800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

120 hp

Weight

6271 kg

Catalogue coverage

Variants represented

Richest spec table

29 rows

Recorded power

120 hp

Recorded weight

6271 kg

Production years

2000-2003

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerSteyrReference

Four-wheel driveReference

Steeringhydrostatic powerReference

Disc brakesReference

Engine

Sisu 6.6L 6-cyl dieselReference

Fuel tank310.4 LReference

Engine89.5 kWReference

Sisu 620.84Reference

turbo dieselReference

6-cylinderReference

Displacement6.6 LReference

Bore/Stroke108 x 120 mmReference

Power89.5 kWReference

Rated RPM2300Reference

Torque459.7 NmReference

Torque RPM1300Reference

PTO & Hydraulics

Total flow115.8 lpmReference

Rear lift9971 kgReference

Rear PTO Type540/750/1000/1400Reference

Dimensions

Wheelbase282 cmReference

Weight6271 kgReference

Front tire480/70R26Reference

Rear tire520/70R38Reference

Ag front480/70R26Reference

Ag rear520/70R38Reference

Length479 cmReference

Height304 cmReference

Transmission

Transmissioncontinuously variableReference

Gearsinfinite forward and reverseReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
