Tractor · 1994Unverified
Steyr M 9078
Steyr M 9078 · 78 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
78 hp
Weight
3950 kg
Hover a source tag to verify
Overview
ManufacturerSteyrReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD optionalReference
Steeringhydrostatic powerReference
Disc brakesReference
Engine
MWM 4.2L 4-cyl dieselReference
Sisu 4.4L 4-cylReference
Fuel tank99.9 LReference
Fuel tank149.9 LReference
Engine58.2 kWReference
MWM WD 401.81Reference
turbo dieselReference
4-cylinderReference
Displacement4.2 LReference
Bore/Stroke105 x 120 mmReference
Power58.2 kWReference
Rated RPM2300Reference
Torque298.3 NmReference
Torque RPM1500Reference
Sisu 420.81Reference
turboReference
Displacement4.4 LReference
Bore/Stroke108 x 120 mmReference
Torque305.1 NmReference
Torque RPM1300Reference
Transmission
16-speedReference
TransmissionsynchroReference
Gears16 forward and 8 reverseReference
Gears16 forward and reverseReference
PTO & Hydraulics
Total flow50.0 lpmReference
Total flow84.0 lpmReference
Rear lift4900 kgReference
Rear PTO Type430/540/ 750/1000Reference
Dimensions
Wheelbase247 cmReference
Weight3950 kgReference
Front tire9.00-16Reference
Rear tire16.9R34Reference
Ag front9.00-16Reference
Ag rear16.9R34Reference
Ag front13.6R24Reference
Length420 cmReference
Height265 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
