The Steyr M 9083 is a mid-range tractor model with an approximate output of 83 hp. It was manufactured between 1994 and 1995. The M 9083 features a 4-cylinder turbocharged diesel engine, coupled with four-wheel drive and a hydrostatic transmission. Its listed operating weight is 3860 kg, and it is suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
83 hp
Weight
3860 kg
Catalogue coverage
Variants represented
2
Richest spec table
33 rows
Recorded power
83 hp
Recorded weight
3860 kg
Transmissions
16-speed
Production years
1994-1995
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerSteyrReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Disc brakesReference
Engine
MWM 4.2L 4-cyl dieselReference
Fuel tank99.9 LReference
Fuel tank149.9 LReference
Engine61.9 kWReference
MWMReference
turbo dieselReference
4-cylinderReference
Displacement4.2 LReference
Bore/Stroke105 x 120 mmReference
Power61.9 kWReference
Rated RPM2100Reference
Torque311.9 NmReference
Torque RPM1500Reference
Transmission
16-speedReference
TransmissionsynchroReference
Gears16 forward and 8 reverseReference
Gears16 forward and reverseReference
PTO & Hydraulics
Total flow50.0 lpmReference
Total flow84.0 lpmReference
Rear lift4900 kgReference
Rear PTO Type430/540/ 750/1000Reference
Dimensions
Wheelbase247 cmReference
Weight3860 kgReference
Front tire13.6R24Reference
Rear tire16.9R34Reference
Ag front13.6R24Reference
Ag rear16.9R34Reference
Length417 cmReference
Height268 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
