Tractor · 1994Unverified
Steyr M 9094
Steyr M 9094 · 94 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
94 hp
Weight
3900 kg
Hover a source tag to verify
Overview
ManufacturerSteyrReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Disc brakesReference
Engine
MWM 4.2L 4-cyl dieselReference
Sisu 4.4L 4-cylReference
Fuel tank149.9 LReference
Engine70.1 kWReference
MWM WD 401.85Reference
turbo dieselReference
4-cylinderReference
Displacement4.2 LReference
Bore/Stroke105 x 120 mmReference
Power70.1 kWReference
Rated RPM2300Reference
Torque352.6 NmReference
Torque RPM1500Reference
Sisu 420.83Reference
turboReference
Displacement4.4 LReference
Bore/Stroke108 x 120 mmReference
Power69.4 kWReference
Torque356.6 NmReference
Torque RPM1300Reference
Transmission
16-speedReference
TransmissionsynchroReference
Gears16 forward and 8 reverseReference
Gears16 forward and reverseReference
PTO & Hydraulics
Total flow50.0 lpmReference
Total flow84.0 lpmReference
Rear lift4900 kgReference
Rear PTO Type430/540/ 750/1000Reference
Dimensions
Wheelbase247 cmReference
Weight3900 kgReference
Front tire14.9R24Reference
Rear tire16.9R38Reference
Ag front14.9R24Reference
Ag rear16.9R38Reference
Length420 cmReference
Height266 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
