The Steyr M 948 is a tractor with an approximate power output of 48 hp, positioning it at the lower end of its class. It was produced from 1996 to 2001. This model features a 3-cylinder diesel engine combined with mechanical front-wheel drive and a hydrostatic transmission. It has an operating weight of 2710 kg and is suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
48 hp
Weight
2710 kg
Catalogue coverage
Variants represented
2
Richest spec table
32 rows
Recorded power
48 hp
Recorded weight
2710 kg
Transmissions
16-speed
Production years
1996-2001
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerSteyrReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD optionalReference
Steeringhydrostatic powerReference
Disc brakesReference
Engine
Perkins 2.7L 3-cyl dieselReference
Fuel tank73.1 LReference
Engine35.8 kWReference
Perkins 903.27Reference
dieselReference
3-cylinderReference
Displacement2.7 LReference
Bore/Stroke95 x 127 mmReference
Power35.8 kWReference
Rated RPM2250Reference
Torque189.8 NmReference
Torque RPM1300Reference
Transmission
16-speedReference
TransmissionsynchroReference
Gears16 forward and 8 reverseReference
PTO & Hydraulics
Total flow37.9 lpmReference
Rear lift2290 kgReference
Rear PTO Type430/540/ 750/1000Reference
Dimensions
Wheelbase212 cmReference
Weight2710 kgReference
Front tire7.50-16Reference
Rear tire14.9R28Reference
Ag front7.50-16Reference
Ag rear14.9R28Reference
Ag front10.5R20Reference
Length352 cmReference
Height233 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
