The Steyr M 952 is a tractor with a power rating of approximately 52 hp, placing it within the lighter end of its class. It was manufactured from 2001 to 2004 and is equipped with a 3-cylinder diesel engine, mechanical front-wheel drive and a hydrostatic transmission. The tractor has an operating weight of 2700 kg and is suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
52 hp
Weight
2700 kg
Catalogue coverage
Variants represented
2
Richest spec table
33 rows
Recorded power
52 hp
Recorded weight
2700 kg
Transmissions
16-speed
Production years
2001-2004
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerSteyrReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD optionalReference
Steeringhydrostatic powerReference
Disc brakesReference
Engine
Perkins 2.7L 3-cyl dieselReference
Fuel tank73.1 LReference
Engine38.8 kWReference
Perkins 903.27TReference
dieselReference
3-cylinderReference
Displacement2.7 LReference
Bore/Stroke95 x 127 mmReference
Power38.8 kWReference
Rated RPM2250Reference
Torque192.6 NmReference
Torque RPM1400Reference
Transmission
16-speedReference
TransmissionsynchroReference
Gears16 forward and 8 reverseReference
PTO & Hydraulics
Total flow34.1 lpmReference
Rear lift2500 kgReference
Rear PTO Type430/540/ 750/1000Reference
Dimensions
Wheelbase212 cmReference
Weight2700 kgReference
Front tire7.50-18Reference
Rear tire14.9R28Reference
Ag front7.50-18Reference
Ag rear14.9R28Reference
Ag front275/80R20Reference
Ag rear380/85R28Reference
Length357 cmReference
Height237 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
