Tractor · 2022Unverified

Summit Tractors TX25H

Name: Summit Tractors TX25H
Brand: Summit Tractors

Summit Tractors TX25H — Compact Utility tractor · 25 hp. Reference specifications; pending source verification.

The Summit Tractors TX25H is a compact tractor with a rated output of 25 horsepower. It was manufactured in 2022. The TX25H features a 3-cylinder diesel liquid-cooled engine driving through four-wheel drive and a hydrostatic transmission. Its listed weight ranges from 2513 to 3406 pounds and is suitable for tasks on areas of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

25 hp

Max power

24.7 hp

Weight

2513 to 3406 pounds

Catalogue coverage

Variants represented

Richest spec table

91 rows

Recorded power

25 hp

Recorded weight

1139 kg

Transmissions

hydrostatic

Production years

2022-2022

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorSummit TractorsReference

ManufacturerITLReference

Compact Utility tractorReference

Original price$18,999 (2022, with loader)Reference

Four-wheel driveReference

Final drivesmechanical rearReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS.Reference

Engine

Mitsubishi 1.3L 3-cyl dieselReference

Fuel tank26.1 LReference

Engine (gross)18.4 kWReference

Mitsubishi S3L2Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.3 LReference

Bore/Stroke78 x 92 mmReference

EmissionsTier IVReference

Power (gross)18.4 kWReference

Fuel systemindirect injectionReference

Rated RPM2500Reference

StarterelectricReference

Starter volts12Reference

Fuel TypeDieselReference

No of Cylinders3 cylindersReference

Rated engine speed2,500 rpmReference

AspirationNatural AspirationReference

Cooling systemLiquidReference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (2-range)Reference

forward and reverse options2-RangeReference

Wheel Drive4WDReference

PTO & Hydraulics

PTO (claimed)13.4 kWReference

Typeopen centerReference

Rear valves1Reference

Mid valves2Reference

Pump flow18.2 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift (at ends)599 kgReference

Rear lift (at 24"/610mm)529 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulicReference

Rear PTO Type540 (1.375)Reference

Mid PTOindependentReference

Mid PTO Type2100Reference

Dimensions

Wheelbase156 cmReference

Weight2513 to 3406 poundsReference

Industrial front23x8.50-12Reference

Industrial rear12-16.5Reference

Length288 cmReference

Width137 cmReference

Height (ROPS)233 cmReference

Shipping weight1139 kgReference

Operating weight1544 kgReference

Clearance (front axle)24 cmReference

Summit Tractors TX25H attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps42Reference

Battery volts12Reference

Alternator size12V42AReference

General

Make & ModelMitsubishi 24.7 hp EPA Tier 4 Diesel EngineReference

Air cleanerDual ElementReference

Cruise controlTRUEReference

Differential lockAvailableReference

SCV controljoystickReference

Rollover protective structureFoldingReference

Capacities

Capacity80.42 cu.in.Reference

Power

Max Power24.7 hpReference

PTO

PTO Power18 hpReference

Rear PTO PowerAvailableReference

Rear PTO ControlElectric/HydroReference

Rear PTO RPM540 rpmReference

Mid PTO RPM2,100 rpmReference

Steering & brakes

BrakesWet DiscReference

Steering typeHydraulicReference

Hydraulics

Remote Valves1 SetReference

Rear Hitch category (SAE designation)Category 1Reference

Rear Hitch maximum lift capacity599.6 kgReference

Dimensions & weight

Height Over ROPS233.9 cmReference

Overall Length288.5 cmReference

Overall Width137.2 cmReference

Ground Clearance24.4 cmReference

Overall weight1,139.9 kgReference

Wheels & tyres

Rear Wheel TypeGoodyear R14T 12-16.5 (USA)Reference

Front Wheel TypeGoodyear R14T 23x8.50-12 (USA)Reference

Operator station

Cab Seat TypeCoated PVC WeatherproofReference

Seat SuspensionTRUEReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
