The TAFE 3300 is a tractor rated at 26 hp — making it one of the more compact options in its class. Under the hood is a 4-cylinder diesel liquid-cooled engine, driving through four-wheel drive with a hydrostatic transmission. Listed weight is 1389 kg, and it is aimed at jobs of around up to 200 ac. The available specification table below shows both UK and US units.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
26 hp
Weight
1389 kg
Catalogue coverage
Variants represented
2
Richest spec table
40 rows
Recorded power
26 hp
Recorded weight
1389 kg
Transmissions
hydrostatic
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerTAFEReference
Built in IndiaReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Independent wet disc brakesReference
Engine
2.7L 4-cyl dieselReference
Fuel tank39.7 LReference
Engine24.6 kWReference
3A 165 LGReference
dieselReference
4-cylinderReference
liquid-cooled verticalReference
Displacement2.7 LReference
Power24.6 kWReference
Air cleanerdryReference
Rated RPM2700Reference
Starter volts12Reference
Oil capacity5.5 LReference
Coolant capacity2.6 LReference
PTO & Hydraulics
PTO (claimed)19.4 kWReference
Pressure191.4 barReference
Valves2Reference
Total flow31.0 lpmReference
Rear TypeIReference
Rear lift949 kgReference
Rear PTOindependentReference
Rear PTO Type579Reference
Dimensions
Weight1389 kgReference
Front tire8.0-16Reference
Rear tire12.4-24Reference
Ag front8.0-16Reference
Ag rear12.4-24Reference
Length310 cmReference
Width167 cmReference
Height223 cmReference
Ground clearance34 cmReference
Electrical
Charging amps40Reference
Battery volts12Reference
Transmission
TransmissionhydrostaticReference
Gears3-range infinite forward and reverseReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
