The TAFE 3600 is a compact tractor model with a rating of 28 hp. It is equipped with a 4-cylinder diesel liquid-cooled engine, which drives a four-wheel drive system through a hydrostatic transmission. The listed weight of the TAFE 3600 is 1339 kg, and it is suitable for tasks involving areas of approximately 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
28 hp
Weight
1339 kg
Catalogue coverage
Variants represented
2
Richest spec table
41 rows
Recorded power
28 hp
Recorded weight
1339 kg
Transmissions
hydrostatic
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerTAFEReference
Built in IndiaReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Independent wet disc brakesReference
Engine
1.8L 4-cyl dieselReference
Fuel tank39.7 LReference
Engine26.8 kWReference
S4 L2Reference
dieselReference
4-cylinderReference
liquid-cooled verticalReference
Displacement1.8 LReference
Bore/Stroke78 x 92 mmReference
Power26.8 kWReference
Air cleanerdryReference
Rated RPM2700Reference
Starter volts12Reference
Oil capacity4.5 LReference
Coolant capacity2.6 LReference
PTO & Hydraulics
PTO (claimed)20.9 kWReference
Pressure191.4 barReference
Valves2Reference
Total flow31.0 lpmReference
Rear TypeIReference
Rear lift949 kgReference
Rear PTOindependentReference
Rear PTO Type579Reference
Dimensions
Weight1339 kgReference
Front tire8.0-16Reference
Rear tire12.4-24Reference
Ag front8.0-16Reference
Ag rear12.4-24Reference
Length310 cmReference
Width167 cmReference
Height223 cmReference
Ground clearance34 cmReference
Electrical
Charging amps50Reference
Battery volts12Reference
Transmission
TransmissionhydrostaticReference
Gears3-range infinite forward and reverseReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
