The TAFE 3840 is a tractor model with a rated power of 38 horsepower, which positions it at the lighter end of its class. It features a 3-cylinder diesel liquid-cooled engine, paired with a hydrostatic transmission. The tractor's listed operating weight is 1749 kilograms. It is suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
38 hp
Weight
1749 kg
Catalogue coverage
Variants represented
2
Richest spec table
39 rows
Recorded power
38 hp
Recorded weight
1749 kg
Transmissions
8-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerTAFEReference
Built in IndiaReference
Steeringhydrostatic powerReference
Drum brakesReference
Engine
2.5L 3-cyl dieselReference
Fuel tank43.9 LReference
Engine28.3 kWReference
S325.3Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke91 x 127 mmReference
Power28.3 kWReference
Air cleanerdryReference
Rated RPM2000Reference
Torque152.0 NmReference
Torque RPM1200Reference
Oil capacity5.7 LReference
Coolant capacity9.8 LReference
Transmission
8-speedReference
Transmissionsliding meshReference
Gears8 forward and 2 reverseReference
PTO & Hydraulics
Valves3Reference
Total flow15.9 lpmReference
Rear lift1100 kgReference
Rear PTO Type540Reference
Dimensions
Wheelbase195 cmReference
Weight1749 kgReference
Front tire6.00x16Reference
Rear tire12.4x28Reference
Ag front6.00x16Reference
Ag rear12.4x28Reference
Length320 cmReference
Width162 cmReference
Height225 cmReference
Ground clearance32 cmReference
Electrical
Charging amps36Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
