TAFE 5040
TAFE 5040 — Utility tractor · 50 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
50 hp
Weight
1859 kg
Hover a source tag to verify
Overview
ManufacturerTAFEReference
Utility tractorReference
Built in IndiaReference
Two-wheel driveReference
Steeringhydrostatic powerReference
Drum brakesReference
Two-post ROPS.Reference
Engine
2.7L 3-cyl dieselReference
Fuel tank43.9 LReference
Engine37.3 kWReference
SJ327EReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.7 LReference
Bore/Stroke95 x 127 mmReference
Power37.3 kWReference
Air cleanerdryReference
Rated RPM2250Reference
Torque180.1 NmReference
Torque RPM1200Reference
Oil capacity5.7 LReference
Coolant capacity9.8 LReference
Transmission
8-speedReference
Transmissionsliding meshReference
Gears8 forward and 2 reverseReference
PTO & Hydraulics
Valves3Reference
Total flow16.0 lpmReference
Rear lift1450 kgReference
Rear PTO Type540Reference
Dimensions
Wheelbase195 cmReference
Weight1859 kgReference
Front tire6.00x16Reference
Rear tire13.6x28Reference
Ag front6.00x16Reference
Ag rear13.6x28Reference
Length320 cmReference
Width162 cmReference
Height227 cmReference
Ground clearance35 cmReference
Electrical
Charging amps36Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
