Tractor · 1983Unverified
Taishan-America 12
Taishan-America 12 — Compact Utility tractor · 12 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
12 hp
Weight
1731 to 2183 pounds
Hover a source tag to verify
Overview
ManufacturerTaishan-AmericaReference
Compact Utility tractorReference
Built in Tsinan, Shandong, ChinaReference
Original price was $3,950 in 1983Reference
Two-wheel driveReference
Manual steeringReference
Mechanical drum brakesReference
Open operator station.Reference
Engine
0.8L 1-cyl dieselReference
Fuel tank14.0 LReference
Engine8.9 kWReference
195Reference
dieselReference
1-cylinderReference
liquid-cooledReference
Displacement0.8 LReference
Power8.9 kWReference
Rated RPM2000Reference
StarterelectricReference
Starter volts6Reference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 1 reverseReference
Clutchdry discReference
PTO & Hydraulics
Rear TypeIReference
Rear lift300 kgReference
Dimensions
Wheelbase130 cmReference
Weight1731 to 2183 poundsReference
Front tire4.00-12Reference
Rear tire7.50-16Reference
Ag front4.00-12Reference
Ag rear7.50-16Reference
Length239 cmReference
Width116 cmReference
Height (steering wheel)123 cmReference
Shipping weight785 kgReference
Operating weight990 kgReference
Ground clearance24 cmReference
Front tread89 cmReference
Rear tread96 cmReference
Electrical
Charging systemgeneratorReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
