The Taishan-America 25 is a tractor with a rated output of approximately 24 horsepower, positioning it at the lighter end of its class. It was manufactured from 1983 to 1985. The vehicle features a 2-cylinder diesel liquid-cooled engine and two-wheel drive with an 8-speed gearbox. Its operating weight is listed as between 2580 and 3252 pounds, suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Weight
2580 to 3252 pounds
Catalogue coverage
Variants represented
2
Richest spec table
42 rows
Recorded power
24 hp
Recorded weight
1170 kg
Transmissions
8-speed gear
Production years
1983-1985
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerTaishan-AmericaReference
Compact Utility tractorReference
Built in Tsinan, Shandong, ChinaReference
Original price was $5,995 in 1983Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
1.6L 2-cyl dieselReference
Fuel tank43.5 LReference
Engine17.9 kWReference
295Reference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement1.6 LReference
Bore/Stroke95 x 115 mmReference
Power17.9 kWReference
Compression19:1Reference
Rated RPM2000Reference
Torque1129.5 NmReference
Torque RPM1650Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 2 reverseReference
PTO & Hydraulics
Rear TypeIReference
Rear lift650 kgReference
Rear PTO Type540Reference
Dimensions
Wheelbase169 cmReference
Weight2580 to 3252 poundsReference
Front tire4.00-16Reference
Rear tire9.5-24Reference
Ag front4.00-16Reference
Ag rear9.5-24Reference
Length300 cmReference
Width135 cmReference
Height (steering wheel)139 cmReference
Shipping weight1170 kgReference
Operating weight1475 kgReference
Ground clearance42 cmReference
Electrical
Charging systemgeneratorReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
