Tractor · 2002Unverified
Terraplane TD100
Terraplane TD100 — Utility tractor · 99 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
99 hp
Weight
4688 kg
Hover a source tag to verify
Overview
DistributorTerraplaneReference
ManufacturerFotonReference
Utility tractorReference
Built in ChinaReference
Four-wheel driveReference
Power steeringReference
Disc brakesReference
Two-post ROPS. Cab optional.Reference
Engine
4.1L 4-cyl dieselReference
Engine (gross)73.5 kWReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.1 LReference
Power (gross)73.5 kWReference
Fuel systemdirect inejctionReference
Rated RPM2400Reference
Starter typeelectricReference
Transmission
18-speed gearReference
TypegearReference
Gears18 forward and 6 reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (claimed)72.0 kWReference
Pressure190.0 barReference
Pump flow45.4 lpmReference
Steering flow39.2 lpmReference
Steering press.100.0 barReference
Rear TypeII/IReference
Rear lift2549 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase238 cmReference
Weight4688 kgReference
Front tire12.4-28Reference
Rear tire16.9-38Reference
Standard tires (ag)Front: 12.4-28. Rear: 16.9-38Reference
Length444 cmReference
Width204 cmReference
Height (cab)264 cmReference
Ground clearance43 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
