Tractor · 2002Unverified
Terraplane TD60
Terraplane TD60 — Utility tractor · 67 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
67 hp
Weight
6503 to 7506 pounds
Hover a source tag to verify
Overview
DistributorTerraplaneReference
ManufacturerFotonReference
Utility tractorReference
Built in ChinaReference
Two- or four-wheel driveReference
Power steeringReference
Two-post ROPS. Cab optional.Reference
Engine
4.3L 4-cyl dieselReference
Fuel tank78.0 LReference
Engine (gross)50.0 kWReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.3 LReference
Bore/Stroke105 x 125 mmReference
Power (gross)50.0 kWReference
Fuel systemdirect inejctionReference
Rated RPM2200Reference
Starter typeelectricReference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 2 reverseReference
Clutchdry discReference
PTO & Hydraulics
Pressure100.0 barReference
Pump flow32.2 lpmReference
Steering flow10.0 lpmReference
Steering press.70.0 barReference
Rear TypeII/IReference
Rear lift928 kgReference
Rear PTOliveReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1836Reference
Dimensions
2WD Wheelbase218 cmReference
4WD Wheelbase221 cmReference
Weight6503 to 7506 poundsReference
Front tire6.50-16Reference
2WD Rear tire14.9-30Reference
2WD Standard tires (ag)Front: 6.50-16. Rear: 14.9-30Reference
4WD Standard tires (ag)Front: 8.30-24. Rear: 14.9-30Reference
Length408 cmReference
Width190 cmReference
2WD Ground clearance40 cmReference
4WD Ground clearance33 cmReference
2WD ROPS2949 kgReference
4WD ROPS3239 kgReference
2WD Cab3114 kgReference
4WD Cab3404 kgReference
Steering wheel180 cmReference
Terraplane TD60 Height
ROPS271 cmReference
Cab248 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
