Tractor · 2002Unverified

Terraplane TD70

Name: Terraplane TD70
Brand: Terraplane

Terraplane TD70 — Utility tractor · 75 hp. Reference specifications; pending source verification.

The Terraplane TD70 is a tractor model with a power rating of 75 hp, placing it in the middle of its class. Manufactured from 2002 to 2004, it is equipped with a 4-cylinder diesel liquid-cooled engine and features four-wheel drive with an 8-speed gearbox. The listed weight range is 6613 to 7616 pounds, and the model is suited for tasks covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

75 hp

Weight

6613 to 7616 pounds

Catalogue coverage

Variants represented

Richest spec table

50 rows

Recorded power

75 hp

Transmissions

8-speed gear

Production years

2002-2004

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorTerraplaneReference

ManufacturerFotonReference

Utility tractorReference

Built in ChinaReference

Two- or four-wheel driveReference

Power steeringReference

Two-post ROPS. Cab optional.Reference

Engine

4.3L 4-cyl dieselReference

Fuel tank78.0 LReference

Engine (gross)55.9 kWReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.3 LReference

Bore/Stroke105 x 125 mmReference

Power (gross)55.9 kWReference

Fuel systemdirect inejctionReference

Rated RPM2200Reference

Starter typeelectricReference

Transmission

8-speed gearReference

TypegearReference

Gears8 forward and 2 reverseReference

Clutchdry discReference

PTO & Hydraulics

Pressure100.0 barReference

Pump flow32.2 lpmReference

Steering flow10.0 lpmReference

Steering press.70.0 barReference

Rear TypeII/IReference

Rear lift1223 kgReference

Rear PTOliveReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@1836Reference

Dimensions

2WD Wheelbase218 cmReference

4WD Wheelbase221 cmReference

Weight6613 to 7616 poundsReference

Front tire6.50-20Reference

2WD Rear tire16.9-28Reference

2WD Standard tires (ag)Front: 6.50-20. Rear: 16.9-28Reference

4WD Standard tires (ag)Front: 8.30-24. Rear: 16.9-28Reference

Length408 cmReference

Width190 cmReference

2WD Ground clearance40 cmReference

4WD Ground clearance33 cmReference

2WD ROPS2999 kgReference

4WD ROPS3289 kgReference

2WD Cab3164 kgReference

4WD Cab3454 kgReference

Steering wheel185 cmReference

Terraplane TD70 Height

ROPS271 cmReference

Cab248 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
