The Terraplane TD80 is a tractor with a rated output of 79 hp, positioning it in the middle of its class in terms of power. Produced from 2002 to 2004, this model features a 4-cylinder diesel liquid-cooled engine, which drives through four-wheel drive and is paired with an 18-speed gearbox. The tractor's listed weight is 4688 kg, and it is designed to handle jobs of up to 200 ac.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
79 hp
Weight
4688 kg
Catalogue coverage
Variants represented
2
Richest spec table
40 rows
Recorded power
79 hp
Recorded weight
4688 kg
Transmissions
18-speed gear
Production years
2002-2004
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
DistributorTerraplaneReference
ManufacturerFotonReference
Utility tractorReference
Built in ChinaReference
Four-wheel driveReference
Power steeringReference
Disc brakesReference
Two-post ROPS. Cab optional.Reference
Engine
4.1L 4-cyl dieselReference
Engine (gross)59.0 kWReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.1 LReference
Power (gross)59.0 kWReference
Fuel systemdirect inejctionReference
Rated RPM2400Reference
Starter typeelectricReference
Transmission
18-speed gearReference
TypegearReference
Gears18 forward and 6 reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (claimed)57.6 kWReference
Pressure190.0 barReference
Pump flow45.4 lpmReference
Steering flow39.2 lpmReference
Steering press.100.0 barReference
Rear TypeII/IReference
Rear lift2243 kgReference
Rear PTOliveReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase238 cmReference
Weight4688 kgReference
Front tire11.2-28Reference
Rear tire16.9-34Reference
Standard tires (ag)Front: 11.2-28. Rear: 16.9-34Reference
Length444 cmReference
Width204 cmReference
Height (cab)264 cmReference
Ground clearance43 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
