The Terrion ATM 3180M is a tractor rated at approximately 182 horsepower, placing it at the higher end of its class. It was produced in 2013 and features a 6-cylinder turbocharged intercooled diesel liquid-cooled engine, paired with four-wheel drive and a powershift transmission. This model is suitable for operations covering 600–1,500 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
182 hp
Catalogue coverage
Variants represented
2
Richest spec table
33 rows
Recorded power
182 hp
Transmissions
24-speed four-speed power shift
Production years
2013-2013
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerTerrionReference
Row-Crop tractorReference
Built in Tambov, RussiaReference
Four-wheel driveReference
Power steeringReference
Cab standard with air-condtioning.Reference
Engine
Deutz 6.1L 6-cyl dieselReference
Fuel tank374.7 LReference
Engine135.7 kWReference
Deutz BF 6M 2012CReference
intercooled turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.1 LReference
Bore/Stroke101 x 126 mmReference
Power135.7 kWReference
Rated RPM2200Reference
Starter typeelectricReference
Transmission
24-speed four-speed power shiftReference
TransmissionZF T7229Reference
Typefour-speed power shiftReference
Gears24 forward and reverseReference
PTO & Hydraulics
Valves4Reference
Pump flow74.9 lpmReference
Rear TypeIIIReference
Controlposition and draft controlReference
Front HitchIIINReference
Rear PTO Type540/540E/1000/1000EReference
Front PTOoptionalReference
Dimensions
Front tire420/85R30Reference
Rear tire520/85R38Reference
Ag front420/85R30Reference
Ag rear520/85R38Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
