Lawn Tractor · 2003Unverified
Toro 14-38Z 74301
Toro 14-38Z 74301 — TimeCutter Z Series · 14 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Hover a source tag to verify
Overview
ManufacturerToroReference
Zero-turn mowerReference
Original price was $2,899 in 2004Reference
Two-wheel driveReference
Power steeringReference
Open operator station.Reference
Engine
14HP Briggs & Stratton 465cc 1-cyl gasolineReference
Briggs & Stratton 280H07Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement28.4 ciReference
Bore/Stroke87 x 78 mmReference
Power (gross)10.4 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TransmissionHydro-GearReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchelectricReference
Dimensions
Front tire10x4Reference
Rear tire18x6.5Reference
Lawn/turf front10x4Reference
Lawn/turf rear18x6.5Reference
Front axleCasterReference
Toro 14-38Z attachments
38" mid-mount mower deckReference
14-38Z Serial Numbers
2003230000001Reference
2004240000001Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
38" Mower deck
Typemid-mount ToroReference
Type2-blade with manual liftReference
Cutting width96 cmReference
Cut height3 to 11 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
