Lawn Tractor · 1964Unverified
Toro Big Red 32 51070
Toro Big Red 32 51070 — Riding lawn mower · 6 hp. Reference specifications; pending source verification.
The Toro Big Red 32 51070 is a compact lawn tractor model with a 6 hp rated output, produced from 1964 to 1965. It features a 1-cylinder petrol air-cooled engine, driving through a two-wheel drive system with a 4-speed gearbox. The model is suited for tasks of approximately 200 acres. The model's specifications are detailed in the following information.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
6 hp
Catalogue coverage
Variants represented
2
Richest spec table
29 rows
Recorded power
6 hp
Transmissions
4-speed
Production years
1964-1965
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerToroReference
Riding lawn mowerReference
Two-wheel driveReference
Manual steeringReference
Mechanical band brakesReference
Open operator station.Reference
Engine
6HP Tecumseh 221cc 1-cyl gasolineReference
Tecumseh V60Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement13.53 ciReference
Bore/Stroke67 x 64 mmReference
Power (gross)4.5 kWReference
StartermanualReference
StarterelectricReference
Starter volts12Reference
Transmission
4-speedReference
Gears4 forward and 1 reverseReference
Toro Big Red 32 attachments
32" mid-mount mower deckReference
Big Red 32 Serial Numbers
1964400001Reference
1965500001Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemmagnetoReference
Battery volts12Reference
32" Mower deck
Typemid-mount ToroReference
Type3-bladeReference
Cutting width81 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
