Lawn Tractor · 1966Unverified
Toro Big Red 34 51070
Toro Big Red 34 51070 — Riding lawn mower · 6 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
6 hp
Weight
127 kg
Hover a source tag to verify
Overview
ManufacturerToroReference
Riding lawn mowerReference
Original price was $490 in 1967Reference
Two-wheel driveReference
Manual steeringReference
Mechanical band brakesReference
Open operator station.Reference
Engine
6HP Tecumseh 221cc 1-cyl gasolineReference
Fuel tank1.9 LReference
Tecumseh V60Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement13.53 ciReference
Bore/Stroke67 x 64 mmReference
Power (gross)4.5 kWReference
StartermanualReference
StarterelectricReference
Starter volts12Reference
Transmission
4-speed friction discReference
Typefriction discReference
Gears4 forward and 1 reverseReference
Dimensions
Wheelbase105 cmReference
Weight127 kgReference
Front tire4.10x3.50Reference
Rear tire8x4.00Reference
Weight27 kgReference
Lawn/turf front4.10x3.50Reference
Lawn/turf rear8x4.00Reference
Length156 cmReference
Width63 cmReference
Height83 cmReference
Toro Big Red 34 attachments
34" mid-mount mower deckReference
Big Red 34 Serial Numbers
1966600001Reference
1967700001Reference
1968800001Reference
1969900001Reference
1970000001Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemmagnetoReference
Battery volts12Reference
34" Mower deck
Typemid-mount ToroReference
Type2-bladeReference
Cutting width86 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
