Lawn Tractor · 2014Unverified
Toro MX5400 74882
Toro MX5400 74882 — Model year 20142015 · 23 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
23 hp
Hover a source tag to verify
Overview
ManufacturerToroReference
Zero-turn mowerReference
Two-wheel driveReference
Power steeringReference
Two-post foldable ROPS.Reference
Engine
23HP Kawasaki 726cc 2-cyl gasolineReference
Fuel tank18.9 LReference
Kawasaki FR691VReference
gasolineReference
2-cylinderReference
air-cooled vertical-shaft V-TwinReference
Displacement44.3 ciReference
Bore/Stroke78 x 76 mmReference
Power (gross)17.2 kWReference
StarterelectricReference
Starter volts12Reference
Oil capacity2.1 LReference
SparkplugNGK BPR4ESReference
Sparkplug gap0.762 mmReference
Transmission
hydrostaticReference
TransmissionHydro-Gear ZT-3100Reference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchelectricReference
Dimensions
Front tire13x6.5Reference
Rear tire22x10-12Reference
Lawn/turf front13x6.5Reference
Lawn/turf rear22x10-12Reference
Length196 cmReference
Height (ROPS)185 cmReference
Height (ROPS)119 cmReference
Front axleCasterReference
Toro MX5400 attachments
54" mid-mount mower deckReference
Electrical
GroundnegativeReference
Battery CCA195Reference
Battery volts12Reference
54" Mower deck
Typemid-mount ToroReference
Type3-blade with manual liftReference
Cutting width137 cmReference
Overall width172 cmReference
Cut height3 to 11 cmReference
Cut positions13Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
