Lawn Tractor · 2011Unverified
Toro SS5060 74632
Toro SS5060 74632 — TimeCutter SS Series · 24 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Hover a source tag to verify
Overview
ManufacturerToroReference
Zero-turn mowerReference
Original price was $3,599 in 2015Reference
Two-wheel driveReference
Power steeringReference
open operator stationReference
Variants
74635California emissionsReference
Engine
24HP Kawasaki 726cc 2-cyl gasolineReference
Fuel tank11.4 LReference
Kawasaki FR691VReference
gasolineReference
2-cylinderReference
air-cooled vertical-shaft V-TwinReference
Displacement44.3 ciReference
Bore/Stroke78 x 76 mmReference
Power (gross)17.9 kWReference
StarterelectricReference
Starter volts12Reference
Oil capacity2.0 LReference
SparkplugNGK BPR4ESReference
Sparkplug gap0.762 mmReference
Transmission
hydrostaticReference
TransmissionHydro-Gear ZT-2200Reference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
Mid PTOindependentReference
ClutchelectricReference
Dimensions
Front tire13x5Reference
Rear tire18x9.5Reference
Lawn/turf front13x5Reference
Lawn/turf rear18x9.5Reference
Length185 cmReference
Height102 cmReference
Front axleCastersReference
Toro SS5060 attachments
50" mid-mount mower deckReference
SS5060 Serial Numbers
2011311000001Reference
2012312000001Reference
2013313000001Reference
2014314000001Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery CCA195Reference
Battery volts12Reference
50" Mower deck
Typemid-mount ToroReference
Type3-blade with manual lever liftReference
Cutting width127 cmReference
Overall width160 cmReference
Cut height3 to 11 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
